API 682 Seal Plans Application Guide
Mechanical Seal Support Systems
When rotating equipment fails, it’s often due to a seal failure. In fact, about 40% of all unscheduled critical pump shutdowns are caused by mechanical seal failures. Swagelok’s seal plans maximize the life of mechanical seals and the reliability of rotating equipment by maintaining lubrication and pressure with properly conditioned fluid flows. This application guide steps through the options.
Contents
Guided by the publication API 682: Pumps - Shaft Sealing Systems for Centrifugal and Rotary Pumps, Swagelok seal support system designs avoid pipe threads and limit the number of connections wherever possible. Based on the fourth edition, the standard design for each plan includes the minimum arrangement of components as detailed in API 682. This 83-page guide shows diagrams and details on mechanical seal support systems and components available from Swagelok. Fill the form to get your copy. In a hurry or have a question? Please give us a call at 780-437-0640.
